Ficha Técnica en PDF
ESPECIFICACIONES TÉCNICAS
| Categoría del Producto | Conectividad / Power Over Ethernet (POE) / Managed 802.3at High Power PoE Switch |
| Marca | Planet Networking |
| SKU | FGSW-2624HPS |
| 10/100/100Base-T | 2 |
| 10/100Base-TX | 24 |
| 1000Base-SX/LX | 2 combo |
| 1000BASE-SX/LX | 2 combo |
| 802.1p CoS | Si / 2 levels |
| 802.1p priority | Si / 2 levels |
| 802.3af / at PoE Port | 24 |
| 802.3x Flow Control | Si |
| Auto MDI/MDI-X | Si |
| Auto-negotiation | Si |
| Configuration backup/recovery | Si |
| Dimension ( W x D x H) | 440x300x44.5 mm |
| EMI / Safety | FCC Class A, CE |
| Fiber Connector Type | SFP |
| Firmware Upgrade | HTTP |
| Frequence | Vary on SFP |
| Jumbo Frame | 1.5K |
| Link Aggregation: 802.3ad LACP | Si |
| Link Aggregation: Groups / Ports per Group | 2 Groups / 4 Ports - Fst Ethernet Ports 1 Groups / 2 Ports - Gigabit port |
| Link Aggregation: Port Trunk | Si |
| Link Aggregation: Static Port Trunk | Si |
| MAC Table | 4K |
| Max. Distance | Vary on SFP |
| Memory Buffer | 2.75Mb |
| Mode | Vary on SFP |
| Multicast: IGMP Querier | Si |
| Multicast: IGMP Snooping | Si |
| Operating | Operating: 0~50 degrees C |
| Password Control Access | Si |
| PoE 802.3af / at Port | 16 |
| PoE Budget | 220 watts |
| PoE Port | 24 |
| PoE Schedule / Power Recycling | Si |
| PoE Standard | 802.3af / 802.3at |
| Port Configure (Speed / Duplex) | Si |
| Port Mirror | TX, RX, Both |
| Port Security | Si |
| Port-Based | Si |
| Power Pin Assignment | 1/2(+), 3/6(-) |
| Power Requirement | 100~240V AC, 50/60Hz |
| Power Saving | Si |
| Power Supply | Internal |
| Priority Mode | Strict / WRR |
| Protocol Number (TCP/UDP) | Si |
| PSE Type | End-Span |
| QoS Mode | Port-COS, IP-TOS, 802.1p-COS |
| Queue | 2 |
| Rackmountable | Si |
| Rate Control: Egress | Si / 128K~8M |
| Rate Control: Ingress | Si / 128K~8M |
| SNMP Trap | Si |
| Spanning Tree Protocol: 802.1D STP | Si |
| Spanning Tree Protocol: 802.1S MSTP | Si |
| Spanning Tree Protocol: 802.1w RSTP | Si |
| Spanning Tree: 802.1D | Si |
| Spanning Tree: 802.1w | Si |
| Storage | Storage: -10~70 degrees C |
| Storm Control: Broadcast | Si |
| Storm Control: Multicast | Si |
| Storm Control: Unicast | Si |
| Switch Fabric | 8.8Gbps |
| Throughput (packet per second@64 bytes) | 6.54Mpps |
| VLAN: 802.1Q VLAN | Si |
| VLAN: Active VLAN | 30 |
| VLAN: Active VLANs | 30 |
| VLAN: Asymmetric VLAN | Si |
| VLAN: MTU VLAN | Si |
| VLAN: Port-Based | Si |
| VLAN: Port-Based VLAN | Si |
| Web Management | Si |
