Ficha Técnica en PDF
ESPECIFICACIONES TÉCNICAS
| Categoría del Producto | Conectividad / Vigilancia sobre IP / Vigilancia para Retail / Hybrid DVR |
| Marca | Planet Networking |
| SKU | HDVR-430 |
| Additional Camera | Manual/Smart Camera Search |
| Audio Format | G.711A |
| Audio Interface | 2 x audio-in. 1 x audio-out |
| Audio Type | 2-way |
| BNC Interface | 4 |
| Button | Menu. ESC. DirectionEnter |
| Compression | H.264 |
| Consumption | 15W (without HDD) |
| Decode Capacity | 1-ch AHD-M |
| Dimensions (W x D x H) | 255 x 225 x 45 mm |
| Display Division | 1. 4 |
| Download | Back up file to specific local HDD partition |
| Encode Capacity | 4-ch AHD-M |
| Ethernet | 1 x RJ45. 10/100BASE-TX |
| Event Type | System Events – |
| Humidity | 10~90% (non-condensing) |
| LED | Power. Record. Alarm |
| Local Playback | 1~4-ch simultaneous playback Supports up to 4-channel playback (local input mode) |
| Log Type | All. System. Config. Storage. Alarm Event. Week Day. Account. Playback |
| Max. Channels | 4-channel cameras |
| Motion Detection | Zones: 192 (16 x 12) detection zonesSensitivity: multi-level sensitivity (only local channels) |
| Network Service | TCP. UDP. HTTP. DHCP. DNS. DDNS. RTSP. NTP. UPnP. FTP. SMTP |
| Operating Temperature | 0~55 degrees C |
| Play Method | Play. Pause. Stop. Slow. Fast. Prev. Frame. Next Frame Search by time. calendar. event. channel |
| Power Requirement | 12V DC. 2A |
| Privileges | Live View. Playback. System Configurations. Camera Configurations. Recording Configuration. Event Configuration. Maintenance |
| Record | Manual. alarm. motion detection. schedule |
| Remote Session | 5 |
| Resolution | IP camera: 1080p/720p Analog camera: AHD-H (1080p). AHD-M (720p). AHD-L (960H). D1. HD1. CIF |
| Security | Password protection. IP address filtering |
| Snapshot | Video snapshot in JPEG format |
| Software Utility | Search utility. CMS. App |
| Storage Device | 1 x 3.5” SATA hard disk connector (max. 4TB) |
| Storage Temperature | 0~60 degrees C |
| USB Interface | 2 x USB 2.0 for backup device and mouse |
| Video Interface | VGA/HDMI video interface |
| Video System | PAL (625line. 50f/s)NTSC (525line. 60f/s) |
| Weight | 1.7kg |
