Ficha Técnica en PDF
ESPECIFICACIONES TÉCNICAS
| Categoría del Producto | Conectividad / Ethernet Industrial / Switch PoE no administrable Riel DIN 10/100M |
| Marca | Planet Networking |
| SKU | IFGS-1022HPT |
| 10/100BASE-TX | 8 |
| 1000BASE-SX/LX | 1 |
| 802.3x Flow Control | Si |
| Alarm: Event Relay | Power Fail |
| Alarm: Relay current carry ability | 1A @ DC 24V |
| Auto MDI/MDI-X | Si |
| Auto-negotiation | Si |
| Dimension ( W x D x H) | 72 x 107 x 161 mm |
| EMI / Safety | FCC Class A, CE |
| Enclosure | IP30 / Metal |
| Fiber Connector Type | SFP |
| Installation: DIN-Rail | Si |
| Installation: Wall Mount | Si |
| MAC Table | 16K |
| Memory Buffer | 4Mb |
| Operating | Operating: -40~75 degrees C |
| PoE Budget | 240 watts max. |
| PoE Port | 8 |
| PoE Standard | 802.3af/at |
| Power Pin Assignment | 1/2(+), 3/6(-) |
| Power Requirement | 48~46 DC |
| Protection : ESD (Ethernet) | 6KV |
| Protection : Surge(Power) | 6KV |
| PSE Type | End-Span |
| Redundant Power | 48~46 DC |
| Storage | Operating: -40~75 degrees C |
| Switch Fabric | 5.6Gbps |
| Throughput (packet per second@64 bytes) | 4.1Mpps |
