Ficha Técnica en PDF
ESPECIFICACIONES TÉCNICAS
| Categoría del Producto | Conectividad / Automatización del Hogar / HDMI sobre IP |
| Marca | Planet Networking |
| SKU | IHD-210PT |
| Audio | 2-ch uncompressed audio |
| Buttons | Reset button x 1 |
| Cabling | Cat5e/6 UTP cable |
| Channel Switching | DIP (64 channels) |
| Compression | H.264 format for video encoder/decoder.MPEG 1 Layer II format for audio encoder/decoder |
| Dimensions (W x D x H) | 130 x 82 x 30.25 mm |
| Emission | FCC. CE |
| HDMI Interface Compliance | HDMI 1.4a |
| IR | 3.5mm jack for IR emitter cable |
| LED | Numerical LED display |
| Management Interfaces | Search Tool |
| Maximum Distance (between unit and PoE switch) | 100 meters (330 feet) over CAT5e/6 cable |
| Media Stream Bandwidth (max.) | 15Mbps |
| Network Interface | RJ45 port (10/100BASE-TX Ethernet) x 1 |
| Operating | Temperature: 0~55 degrees CRelative Humidity: 5~90% (non-condensing) |
| Packet Contents | Media Extender x 1Quick Installation Guide x 1IR Emitter Cable x 1 |
| Power Consumption | 7W (each unit) |
| Power Supply | IEEE 802.3af/at PoE+5V DC. 2A |
| Protocol | TCP. UDP. RTSP. RTP. DHCP. IGMP Snooping. Multicast. IPv4 |
| Resolution Identification | EDID (Extended Display Identification Data) |
| Security | HDCP compliant |
| Serial Interface | DB-9 female connector for RS232 x 1 |
| Standards Compliance | IEEE 802.3 10BASE-TIEEE 802.3u 100BASE-TXIEEE 802.3af/at PoE+ |
| Storage | Temperature: -10~60 degrees CRelative Humidity: 5~90% (non-condensing) |
| System Expandability (max.) | 64 groups |
| Video In Interface | HDMI A Type female connector x 1 |
| Video In Resolution | 1080p @ 60/50 Hz1080p @30/25 Hz1080i @ 60/50 Hz720p @ 60/50 Hz480p @ 60/50 Hz 480i @ 60/50 Hz |
| Video Out Interface | HDMI A Type female connector x 1 |
| Video Out Resolution | 1080p @30/25 Hz1080i @ 60/50 Hz720p @ 60/50 Hz480p @ 60/50 Hz 480i @ 60/50 Hz |
| Weight | 290 g |
